Sierra Flame by Amantii 65" Austin Direct Vent Linear Gas Fireplace

Name: Sierra Flame by Amantii 65" Austin Direct Vent Linear Gas Fireplace
Brand: Amantii
SKU: AUSTIN-65G-NG-DELUXE

SKU: AUSTIN-65G-NG-DELUXE

Your Price:

$7,799.00

Fuel Type

Great reasons to buy from us:

Free Shipping
FREE Shipping on Orders over $199
We will beat any price
110% Price Match Guarantee
Fast Shipping
In Stock Orders Ship in 24-48 hours
Huge Discounts
Up To 20% Off! Don't miss out on this limited time offer!

DESIGN INTEGRITY, QUALITY CRAFTSMANSHIP & ATTENTION TO DETAIL

Just like it’s little brother – the Stanford, the new Austin features a sleek contemporary linear look. At 65″ it now features our largest viewing area with our signature large flame presentation.

The Austin comes standard with our Deluxe system including 7 day programmable thermostat remote, 6 stage dual fan control and modulating valve so you can control the flame. This fireplace unit is available in gas and liquid propane (LP by special order).

Contemporary black porcelain panels, black reflective glass and 9 piece rock set all come standard with this stunning gas fireplace. A surround with safety barrier is mandatory for this model.

FEATURES

Borosilicate glass
Flush mount design
38,000 BTU (Stanford)
Electronic Ignition
7 day programmable thermostat deluxe remote
7 stage modulating valve (flame control)
Linear style burner
100% Safety shut off
NG or LP
Top vent only
Black Porcelain panels
Deluxe digital remote control
Dual Fan kit with 6 stage adjustable control
Black reflective fire glass media & 9 piece decorative rock media set
Dual stainless steel pan burner

IDEAL APPLICATIONS

New builds & Renovations
Restaurants
Commercial Spaces
Condominiums

GAS SPECIFICATIONS

Framing Dimensions	Viewing Area	BTUs (NG)		AFUE / P.4 (NG Efficiency)	Weight*
Framing Dimensions	Viewing Area	Hi	Low	AFUE / P.4 (NG Efficiency)	Weight*
39” H x 70-1/2” W x 17 1/2” D	18-1/2” H x 62-3/4” W	38,000	27,000	69.10%	240 lbs.

Venting**	Ceiling / Mantle Height
4” flex vent on exhaust side 7” flex vent on the air intake side	Internl ceiling = 58” from top of unit Mantel height = 45”

**Venting – Any certified 2 ply flex piping can be used. Certified on Duravent, Selkirk, Metal Fab, ICC

DIMENSION

INCLUDED MEDIA & ACCESSORIES

9 Piece Rocks

Stones

Remote

SURROUND DIMENSIONS

Model number	Outside Surround Dimensions (H x W)	Description
AUSTIN-CLEAN-BLK	18.57 x 62.59	Clean Face Black Black Surround with safety barrier
AUSTIN-SB	26.10 x 69.64	Basic trim & safety barrier

GLASS VIEWING AREA

18-1/2” H x 62-3/4” W

OPTIONS & ACCESSORIES

SURROUND OPTIONS
Trim & Barrier- required to complete unit

The clean face, black surround and safety barrier for the Sierra Flame Austin series 65 inch direct vent linear fireplace is sure to improve your hearth experience and safe. This Sierra Flame Austin series surround has a clean and classic design that creates the perfect attractive look, fitting in well with any décor.

This basic trim and safety barrier set is required to complete the fireplaces installation of your Sierra Flame Austin series direct vent linear hearth.

Clean Face Black Surround with safety barrier

Size: 62 Inches x 18 Inches
Color: Black
Clean face black surround with safety barrier
Specifically for the Sierra Flame Austin series

Basic trim & safety barrier

Size: 69 Inches x 26 Inches
Color: Black
Black fireplace insert trim with safety barrier
Specifically for the Sierra Flame Austin series

Clean face surround
Basic black surround with safety barrier
Design Specialties hand crafted overlays

Sierra Flame

Comparison of a Black Surround and a Clean Face

Click to see Optional Decorative Media Options

Customize the look of your electric fireplace by purchasing from our selection of stylish decorative media.

	AMSF‐GLASS‐01 – 1 Box includes approx. 5 lbs of 1/4″ reflective fireglass ‐ 1 sq. ft. of media coverage Color: ‘Clear’
	AMSF‐GLASS‐02 – 1 Box includes approx. 5 lbs of 1/4″ reflective fireglass ‐ 1 sq. ft. of media coverage Color: ‘Light Brown’
	AMSF‐GLASS‐03 – 1 Box includes approx. 5 lbs of 1/4″ reflective fireglass ‐ 1 sq. ft. of media coverage Color: ‘Charcoal’
	AMSF‐GLASS‐04 – 1 Box includes approx. 5 lbs of 1/4″ reflective fireglass ‐ 1 sq. ft. of media coverage Color: ‘Champagne’
	AMSF‐GLASS‐05 – 1 Box includes approx. 5 lbs of 1/4″ reflective fireglass ‐ 1 sq. ft. of media coverage Color: ‘Dark Grey’
	AMSF‐GLASS‐06 – 1 Box includes approx. 5 lbs of 1″ Clear ‘Gem’ fireglass ‐ 1 sq. ft. of media coverage ‘clear’ Color: ‘Clear’
	AMSF‐GLASS‐07 – 1 Box includes approx. 5 lbs of white frosted fireglass ‐ 1 sq. ft. of media coverage ‘white’ Color: ‘White’
	AMSF‐GLASS‐08 – 1 Box includes approx. 5 lbs of dusty purple frosted fireglass ‐ 1 sq. ft. of media coverage ‘white’ Color: ‘Dusty Purple’
	AMSF‐GLASS‐09 – 1 Box includes approx. 5 lbs of amber small bead fireglass ‐ 1 sq. ft. of media coverage ‘amber’ Color: ‘Amber’
	AMSF‐GLASS‐10 – 1 Box includes approx. 5 lbs of small bead fireglass ‐ 1 sq. ft. of media coverage ‘orange’ Color: ‘Orange’
	AMSF‐GLASS‐11 – 1 Box includes approx. 5 lbs of small “suntea’ bead fireglass ‐ 1 sq. ft. of media coverage ‘suntea’ Color: ‘Suntea’
	AMSF‐GLASS‐12 – 1 Box includes approx. 5 lbs of small “black’ bead fireglass ‐ 1 sq. ft. of media coverage ‘black’ Color: ‘Black’
	AMSF‐GLASS‐13 – 1 Box includes approx. 5 lbs of small “sable’ bead fireglass ‐ 1 sq. ft. of media coverage ‘sable’ Color: ‘Sable’

Click to see Optional Designer Media Kits

DESIGN-MEDIA-14PCE

RUSTIC‐14 Piece Log set with deluxe media: stones, pebbles, black fire glass and embers.

Use With:

Bennett
Stanford
Austin
Tahoe
TRV-XL Deep Series
TRV-XT-XL Series
Panorama Deep XT Series
Symmetry XT Series

Click to see Fuel Conversion Kit

This conversion kit for the Sierra Flame Austin series direct vent linear fireplace will help you convert your Austin fireplace from one fuel source to another, just select the right one for you.

Fuel Conversion Kit

Fireplace insert fuel conversion kit

Specifically for the Sierra Flame Austin series

Convert your fireplace unit to use either natural gas or liquid propane

Click to see Venting Components

Below is a list of chimney components that are compatible with this item. If you are comfortable picking the components that you need for venting this item, please choose from the items below.

All models come 4" & 7" Flex Ready

	TERM-KIT Termination kit for 4" & 7" vent Includes: 1 wall thimble, Horizontal term vent, No flex included. * Must supply own flex or purchase 10' 4" x 7" flex length only Size: 4 Inch Color: Black Termination kit for 4 x 7" venting Termination kit for Sierra Flame direct vent fireplaces Venting Requirements: This unit requires venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit. Please Note: Customer supplies their own flex vent pipe.
	SF94217405 If 5' of flex is required, use this kit: "4”X 7” Horizontal Flex Termination Kit w/ 5’ of Flex, Horizontal Termination, Wall Thimble. Includes Coaxial flex lengths, horizontal termination, wall thimble, screw package, sealant
	SF94207410 To extend SF94217405 an additional 10' purchase this: 4” X 7” Coaxial Flex, 10’ Length Extends SF94217405 – 5’ Flex Kit Couplers Sold Separate – SF942074C
	SF942074C 4” X 7” Flex Extension Coupler Kit (1-4” & 1-7”) Includes 2 couplers, 1 for the inner flex and 1 for the outer flex Size: 4 Inch Color: Stainless Steel One 4" flexible vent pipe coupler One 7" flexible vent pipe coupler 4" x 7" flexible vent pipe extension coupler kit *Venting Requirements: This unit requires venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit.
	DURA-HARD For Hard pipe only installations Adapter to use hard pipe off of fireplace Size: 4 Inch Transitional adaptor Constructed from galvanized steel Connects flexible vent pipe to rigid vent pipe *Venting Requirements: This unit requires venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit.
	DURA-FLEX To convert from flex to hard pipe Galvanized adapter to go from flex to hard pipe Size: 3 Inch Transitional adaptor Safely transitions flexible vent pipe to rigid vent sections *Venting Requirements: This unit requires venting pipe with an inner diameter of 4 Inches. Please see the Venting Components section on this page if available for venting pipe that must be used with this unit.

DOWNLOADS
